The filters of pleated cardboard manufactured by AirLink Filtros they are applied in paint booths (dry filtration) in the extraction system, with the aim of retaining paint particles coming from theoversprayManufactured with a double-layer filter element made of 100% cellulose Kraft paper.
The pleated cardboard filter works on the principle of inertial separation: the airflow changes direction, causing the heavier particles to stick to the walls of the pleated cardboard or fall off.
Length: 8 and 10 meters
Available widths: 900, 1,000 or 1,250 mm
Fold height: 65 mm
Speed | Initial pressure drop | Final pressure drop |
| 0.5 m/s (recommended) | 1,3 mmCA | 13 mmCA |
| 0,75 m/s | 3,0 mmCA | 13 mmCA |
| 1,0 m/s | 5,6 mmCA | 13 mmCA |
| Dust holding capacity | up to 18 kg/m²* | |
| Recommended number of folds | 25 folds/ml |
The use of the ALM-FV fiberglass blanket post-filter is recommended.
Obs.: For manufacturing in other sizes, please consult our technical/commercial department.
Materials available immediately. Please check available sizes and styles at the time of closing.
