High efficiency, low energy consumption and long service life for critical applications.
The fine filters AirLink Filtros AL-BRF model They are developed with a filter element in paper hydrophobic pleated elulosic, offering high performance in the retention of fine particles larger than 0.4μ in air supply and extraction systems. Suitable for applications that require large volumes of filtered air with stable efficiency and low pressure drop throughout its entire useful life.
Dimensions (mm) | Caudal (m³/h) | Initial Loss (Pa) | Final Loss (Pa) |
| 595 x 595 x 78 | 2250 | 140 | 600 |
| 595 x 595 x 292 | 4250 | 140 | 600 |
| 290 x 595 x 78 | 1125 | 140 | 600 |
| 290 x 595 x 292 | 2250 | 140 | 600 |
Consult our technical team for recommendations tailored to your project.
