Disposable Air Filters

Filtration Classes G3/G4/M5 (ABNT/EN779)

The main applications:

The filtersAL-MP They are ideal for a wide variety of uses, such as:

Fan Coils: For efficient and controlled climate control.
Air Conditioning Systems: Ensuring air quality in HVAC systems.
Ventilation Systems: Air filtration in industrial and commercial environments.
Prefiltration for Fine and Absolute Filters: Extend the lifespan of fine and absolute filters and ensure maximum protection.
Electric Motor Air Intake: It protects engines against particles and dirt.
Paint Booths: Air quality assurance in controlled painting environments.

Advantages of the AL-MP Air Filter

High filtration efficiency: It offers excellent performance in removing particles of different sizes, guaranteeing an environment with cleaner air.
Strength and durability: The combination of high-quality materials ensures wear resistance and a longer filter lifespan.
Versatility: Available in various dimensions, these filters can be adapted to different ventilation systems and industrial needs.

ISO 16890 Coarse Filtration Classes

AirLink Disposable Air Filters model AL-MP they are designed to offer superior performance in removing particles from the air. Manufactured with a frame of reinforced cardboard and perforated metal mesh these filters guarantee high mechanical resistance and dimensional stability, even under demanding conditions.

Composition and Quality

He filter medium It consists of a synthetic fiber mat, a material known for its high dust retention capacity and durability. These filters are ideal for environments requiring superior air quality, such as ventilation and air conditioning systems.

Maximum operating temperature: 45°C
Maximum relative humidity: 60%

The filtration classes comply with Brazilian standards ABNT NBR-16101 and EN779:2012, with the rankings G3, G4 and M5 In addition, the filters AL-MP they are compatible with the standard ISO 16890, providing a broader assessment of filtration efficiency.

Technical Specifications

Dimensions (mm)	Caudal (m³/h)	Initial Pressure Loss (Pa)	Final Pressure Loss (Pa)
300 x 300 x 48	800	60	250
300 x 600 x 48	1600	60	250
500 x 500 x 48	2200	60	250
500 x 600 x 48	2700	60	250
600 x 600 x 48	3200	60	250

Why choose AirLink AL-MP Air Filters?

Compliance with quality standards: Complies with the standards ABNT, EN779and ISO 16890 guaranteeing the safety and effectiveness of the product.
High-quality performance: With excellent particle retention efficiency, these filters are ideal for demanding environments.
Greater durability and resistance: The reinforced structure offers greater resistance to wear, increasing the filter’s lifespan.
Easy installation and maintenance: Optimized design for easy filter installation and replacement.
