The fine air filters supplied by AirLink Filters, model AL-BRF/P made of cellulose paper, they are suitable for installations that require large volumes of filtered air and a long lifespan.
They have a high capacity for accumulating fine particles and greater durability.
The frames can be made of galvanized sheet metal, aluminum, stainless steel, or cardboard.
Filtration class: F8 (ABNT)
Maximum working relative humidity: 80 %
Maximum operating temperature: 80 °C
Dimensions (mm) | Caudal (m³/h) | Initial pressure loss (Pa) | Final pressure loss (Pa) |
| 595 x 595 x 78 | 2250 | 140 | 600 |
| 290 x 595 x 78 | 1125 | 140 | 600 |
Data relating to standard filters obtained under test conditions with air speed of 2.5 m/s.
OBS: For manufacturing in other dimensions, please consult our technical-commercial department.
