Activated Carbon Cartridges for Water Filters

Drinking water filtration in residences, businesses and industries
Systems of reverse osmosis (pre-filtration)
Refrigeration equipment, drinking fountains, coffee and ice machines
Food and pharmaceutical industries to improve taste and safety
Elimination of Free chlorine, unpleasant taste and smell of the water
Purification of aqueous and gaseous solutions with chemical compatibility

Efficient removal of chlorine, odors and tastes unwanted
High adsorption capacity thanks to the vacuum-compacted structure
5 micron filtration with high efficiency in particle retention
Design that minimizes premature blockage increasing the cartridge’s lifespan
Compatible with standard market cases in different dimensions
Ideal for those looking for quality, performance and economy
Approved for potable water systems and critical applications

Composition: Compact activated carbon molded into a block
Filtration level :5 microns
Shell Material: Polypropylene
Sealing: Gasket Hello-N
Available external diameters: 2 1/2″ and 4 1/2″
Standard heights: 5″, 10″, 20″
High chemical resistance for applications in aggressive environments
Maximum operating temperature: 52 ºC

Technical Information

Height: 5″, 10″ and 20″
Inner diameter: 28 mm
Outer diameter: 2 1/2″ or 4 1/2″
Filtration level: 5 microns
Material: Compact activated carbon

Model	Dimensions	Caudal *	Pressure	Temperature
AL-A/CA	5″ X 2,5″	150 L/H	Δp 4 kgf/cm²	52 ºC
AL-A/CA	10″ X 2,5″	300 L/H	Δp 4 kgf/cm²	52 ºC
AL-A/CA	20″ X 2,5″	600 L/H	Δp 4 kgf/cm²	52 ºC
AL-A/CA	10″ X 4,5″	900 L/H	Δp 4 kgf/cm²	52 ºC
AL-A/CA	20″ X 4,5″	1200 L/H	Δp 4 kgf/cm²	52 ºC

OBS: If you need other models, please contact our technical consultants.

Combined filtration: particle removal + contaminant adsorption
Excellent performance as a pre-filter in reverse osmosis systems
Ideal for critical applications that require purity, stability and chlorine control
Custom models available upon request: consult our technicians for personalized solutions

Technical data sheet in PDF and certificates available upon request
